FOUR POINT PROBE

measure the electrical resistivity or sheet resistance of materials — typically semiconductors, thin films, and coatings
Read More

BENCHTOP SURFACE PROFILER

measure and characterise the topography of material surfaces, including: profile of features (valleys, peaks, scratches)
Read More

CONTACT ANGLE

Measures the contact angle of a liquid droplet on a solid surface to determine wettability, hydrophobicity/hydrophilicit
Read More

3D PRINTER

create three-dimensional solid objects from a digital 3D model by depositing materials layer by layer.

THERMAL EVAPORATOR

used for thin‑film deposition of metals, organics or other materials by thermal (resistive) evaporation under high/ultra
Read More

DIAMOND CUTTING SAW

Used to cut, section, or dice hard materials such as metals, ceramics, semiconductors, glass, composites, and crystals.

HIGH END OSCILLOSCOPE

A high‑performance digital oscilloscope designed to measure, visualize and analyze electrical waveforms and their behavi
Read More

SEMICONDUCTOR PARAMETRIC ANALYZER

Used for electrical characterization of semiconductor devices, such as MOSFETs, diodes, thin-film devices, sensors, and
Read More

IMPEDANCE ANALYZER

Measures the complex electrical impedance of components, materials or circuits as a function of frequency.

MUSE CELL ANALYZER

A benchtop flow cytometry-based system for cell counting, viability, apoptosis, and cell cycle analysis.

NANOINDENTER

measures how materials respond mechanically (hardness, modulus, creep, etc.) at very small scales (nanometres to microme
Read More

SPECTROMETER (EDX)

Detects and analyzes the elemental composition of a sample.
